Mastervolt ChargeMaster Plus battery charger 44321105 24/110-2

ChargeMaster Plus is the new generation of battery chargers, which combines multiple functions in one compact device. This battery charger saves costs and simplifies the system by eliminating the need for additional battery chargers. This versatile device charges virtually any combination of two batteries quickly and safely and can be used anywhere in the world.Battery's Best FriendThe 'Battery's Best Friend' architecture enables the ChargeMaster Plus to charge various batteries with different chemical compositions, sizes and voltages simultaneously. Of course, according to the fast and safe 3-step+ charging method.Also unique are:

• Revival mode: charges even fully discharged batteries without any problems
• Priority Charge: faster charging because the available power is allocated to the empty battery
• Reduced second output to prevent overload of the smaller secondary battery
• Multi Voltage: Charge 12V and 24V (starter) batteries without additional accessories Worldwide charging The ChargeMaster Plus can handle all possible mains voltages and frequencies worldwide. The battery charger is resistant to high temperatures and large voltage fluctuations. This makes this battery charger extremely suitable for the most severe maritime or mobile conditions. In addition, the ChargeMaster Plus has CE, ABYC, UL, SAE, CEC/DOE and RCM/C-Tick certification. Easy to use The ChargeMaster Plus clearly shows the charging phase of all outputs. Robust and ergonomic connections of this device save installation time. And setting the second output is also simple using the dip switches. Powerful connections In modern systems, all components work together. The CAN-based MasterBus ensures that the ChargeMaster Plus can communicate with displays, shunts and energy systems. Models with the addition "CZone Integrated" not only support MasterBus, but also CZone and NMEA communication, without the need for additional interfaces. The Chargemasters Plus series can be configured via MasterBus, or accepts a CZone configuration file like any other CZone device. Other communication standards such as ModBus, CANopen, LinBus, etc. are supported with additional interfaces. This wide range of communication interfaces makes the ChargeMaster Plus ideally suited for system integration. In addition, all ChargeMaster Plus models can serve as a power supply for delicate communication equipment or during the (dis)assembly phase of a boat.Features
• Multifunctional battery charger with two outputs, the second output is current limited to prevent overcharging
• Charges Lithium Ion, Gel, AGM, and large or small battery packs with a single battery charger
• Generous specifications: provides 10% more power at 28.5V and 80% charging capacity at 60øC / 140øF
• Safe Charge: recognizes the charge status of your batteries and thus extends their lifespan
• Wide working range of 80-275V AC, 35-70Hz
• Compact, easy to connect and quick to install
